HBQ 747(H)蓄能式液控緩閉閥帶旁通聯動主要外形尺寸
Main dimension of HBQ 747(H) storage tank type hydraulic control slow closing valve with bypass valve combination > |
公稱通徑
DN
Nominal
Diameter
DN
|
L
蝶閥
L-butterfly
valve |
L1 |
L2
max |
L2
min |
L3 |
參考選型
Recommended valVe selection
|
使用壓力
Working
pressure |
手動閥
Manual Valve
|
電動閥
Vectne Valve
|
排氣閥
Vent Valve
|
排氣檢修閥
Vent valve for
maintenance |
排污閥
Drain valve |
| 500 |
229
|
350
|
340 |
300 |
350
|
50D343H
|
50D943H
|
50QB1 50CARX |
50241H 50Q41F |
50241H 50Q41F |
P≤16 |
| 350 |
360 |
360 |
50241H 50Q41F |
502941H 50Q941F |
P≥25 |
| 600 |
267
|
380
|
360 |
320 |
380
|
60D343H
|
60D943H
|
65QB1 65CARX |
65241H 65Q41F |
65241H 65Q41F |
P≤16 |
| 390 |
400 |
400 |
60241H 50Q41F |
602941H 50Q941F |
P≥25 |
| 700 |
292
|
430
|
380 |
340 |
430
|
80D343H
|
80D943H
|
80QB1 80CARX |
80241H 80Q41F |
80241H 80Q41F |
P≤16 |
| 430 |
450 |
450 |
80241H 80Q41F |
802941H 80Q941F |
P≥25 |
800 |
318
|
480
|
400 |
360 |
480
|
80D343H
|
80D943H
|
80QB1 80CARX |
80241H 80Q41F |
80241H 80Q41F |
P《16 |
| 470 |
500 |
500 |
80241H 80Q41F |
802941H 80Q941F |
P≥25 |
900 |
330
|
480
|
430 |
390 |
480
|
100D343H
|
100D943H
|
100QB1 100CARX |
100241H 100Q41F |
100241H 100Q41F |
P≤16 |
| 510 |
500 |
500 |
100241H 100Q41F |
1002941H 100Q941F |
P≥25 |
1000 |
410
|
520
|
430 |
390 |
520
|
100D343H
|
100D943H
|
100QB1 100CARX |
100241H 100Q41F |
100241H 100Q41F |
P≤16 |
| 550 |
550 |
550 |
100241H 100Q41F |
1002941H 100Q941F |
P≥25 |
1200 |
470
|
550
|
450 |
410 |
550
|
125D343H
|
125D943H
|
125QB1 125CARX |
125241H 125Q41F |
125241H 125Q41F |
P≤16 |
| 630 |
600 |
600 |
125241H 125Q41F |
1252941H 125Q941F |
P≥25 |
| 1400 |
530
|
550
|
450 |
410 |
550
|
150D343H
|
150D943H
|
150QB1 150CARX |
150241H 150Q41F |
150241H 150Q41F |
P《16 |
| 710 |
600 |
600 |
150241H 150Q41F |
1502941H 150Q941F |
P≥25 |
| 1600 |
600
|
600
|
470 |
420 |
600
|
150D343H
|
150D943H
|
150QB1 150CARX |
150241H 150Q41F |
200241H 150Q41F |
P≤16 |
| 790 |
650 |
650 |
150241H 150Q41F |
1502941H 150Q941F |
P≥25 |
| 1800 |
670
|
600
|
470 |
420 |
600
|
200D343H
|
200D943H
|
200QB1 200CARX |
200241H 200Q41F |
200241H 200Q41F |
P≤16 |
| 810 |
650 |
650 |
200241H 200Q41F |
2002941H 200Q941F |
P≥25 |
| 2000 |
760
|
650
|
470 |
420 |
650
|
200D343H
|
200D943H
|
200QB1 500CARX |
200241H 500Q41F |
200241H 500Q41F |
P≤16 |
| 950 |
700 |
700 |
200241H 200Q41F |
2002941H 200Q941F |
P≥25 |
| 2200 |
590 |
700 |
500 |
450 |
700 |
200D343H |
200D943H |
200QB1 200CARX |
200241H 200Q41F |
250241H 200Q41F |
|
| 2400 |
650 |
700 |
500 |
450 |
700 |
250D343H |
250D943H |
250QB1 250CARX |
250241H 250Q41F |
150241H 250Q41F |
|
| 2600 |
700 |
700 |
500 |
450 |
700 |
300D343H |
300D943H |
300QB1 300CARX |
300241H 300Q41F |
300241H 300Q41F |
|
| 2800 |
760 |
800 |
520 |
470 |
800 |
300D343H |
300D943H |
300QB1 300CARX |
300241H 300Q41F |
300241H 300Q41F |
|
| 3000 |
810 |
800 |
520 |
470 |
800 |
300D343H |
300D943H |
300QB1 300CARX |
300241H 300Q41F |
300241H 300Q41F |
| |
注：★球閥的結構長度由壓力等級確定。
Note:★The face to face length of ball valve is determined by the pressure rating. |
